Coating Thickness Gauge TP-1M

Name: Coating Thickness Gauge TP-1M
Brand: AERICA ENGINEERING PRIVATE LIMITED
Price: 91237 INR
Availability: InStock

Price 91237 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Coating Thickness Gauge TP-1M Specification

Display
Digital LCD Display

Outer Size
Height: 126 mm, Width: 65 mm, Thickness: 27 mm

Case
ABS Plastic

Sensor Type
Magnetic Induction

Usage
INDUSTRIAL

Material
ABS Body

Product Type
Thickness guague

Weight
0.2 Kilograms (kg)

Grade
Industrial

Application
For measurement of coating thickness on ferrous and non-ferrous metals

Accuracy
(2%+1 m)

Minimum Curvature Radius
Convex: 1.5 mm, Concave: 25 mm

Power Supply
2 x 1.5V AAA batteries

Weight
0.2 kg

Calibration
Zero and Foil Calibration

Data Hold Function
Yes

Auto Power Off
Yes

Resolution
1 m

Minimum Measuring Area
6 mm diameter

Usage
Industrial

Minimum Substrate Thickness
Fe: 0.5 mm, NFe: 0.3 mm

Operating Temperature
0C to 40C

Product Type
Thickness gauge

About Coating Thickness Gauge TP-1M

Coating Thickness Gauge NOVOTEST TP-1M is a thickness gauge for measuring the thickness of various coatings on metals, and with connected specialized probes to the device, user can measure the temperature and humidity of air, surface temperature, calculate the dew point, and also measure the depth of grooves or surface roughness.

The device is very easy to use, ready to use right out of the box, and does not require special user skills. The minimum number of buttons and an intuitive menu makes it an ideal device of operational non-destructive measurement of the thickness of almost any coating with high accuracy.

Precision Measurement for Industrial Applications

The TP-1M thickness gauge offers high-resolution readings, capable of detecting subtle variations as precise as 1 m. This accuracy makes it an essential tool for industries that demand strict quality standards in coating processes, ensuring compliance and consistency without compromising efficiency.

User-Friendly Design and Operation

With an intuitive digital LCD display and robust ABS plastic body, the TP-1M gauge combines ease of use with durability. Its compact dimensions and lightweight construction enable hassle-free handling and storage, making it practical for on-site inspections and continuous use in various industrial settings.

FAQs of Coating Thickness Gauge TP-1M:

Q: How is the Coating Thickness Gauge TP-1M calibrated?

A: The TP-1M is calibrated using both Zero and Foil Calibration methods. This ensures that the measurements are tailored specifically to the substrate type, providing precise results for ferrous and non-ferrous metals alike.

Q: What types of applications is the TP-1M suitable for?

A: This gauge is designed for measuring coating thickness on both ferrous (Fe) and non-ferrous (NFe) metals, making it ideal for use in manufacturing, automotive, aerospace, and metal fabrication industries.

Q: When does the auto power off feature activate on the TP-1M?

A: The auto power off function engages automatically after a period of inactivity to conserve battery life, which is especially useful during extended field operations.

Q: Where is the TP-1M typically used in India?

A: The TP-1M is commonly employed in factories, quality control laboratories, metal workshops, and industrial plants throughout India by manufacturers, traders, and exporters.

Q: What is the data hold function on the TP-1M and how does it benefit users?

A: The data hold function allows users to freeze the current measurement on the display, enabling more convenient recording and analysis of results without rushing.

Q: How does the minimum measuring area affect usage?

A: The TP-1M requires a minimum measuring area of 6 mm in diameter, ensuring reliable readings by preventing interference from substrate irregularities and small surfaces.

Q: What safety and durability features does the gauge offer?

A: Encased in a tough ABS plastic body, the TP-1M is designed for durability. It operates within a safe temperature range (0C to 40C) and includes safety-related features like auto power-off, ensuring long-term reliability and protection during industrial use.
